Low Voltage Cables come in a variety of sizes, materials, and types, each particularly adapted to its uses. Cables consist of three major components: conductors, insulation, and protective outer sheath. The makeup of individual cables varies according to application.
Communications cable is essentially a cable used to transmit information by use of currents of various frequencies. In the basket of communication cables we offer; CCTV, Telephone Cables, CAT 6 UTP Cables, and Co-Axial Cables. These cables are typically used for data transmission, Ethernet connections, electronic circuits and networking
HomeCab-FR wires are ideal for domestic and commercial wiring, designed to handle up to 85°C operating temperature with in-house formulated flame-retardant PVC insulation. They are resistant to steam, boiling water, and have excellent electrical and mechanical properties.
PV Solar cables are designed for connecting photovoltaic power supply systems.They are dedicated to the photovoltaic system direct current (D.C.) side with a nominal D.C. voltage of a 1.5kV. These cables can be used indoor & outdoor for flexible and fixed installations with high mechanical strength in extreme weather conditions.
Control cables encompass a large family of cables manufactured to various IS, BS, EN, VDE, and other international Standards. Our cables are designed for a wide range of application like industrial, signaling, transmission, measurement, control and regulation. These cables allow to transmit power at very low voltage to control the process or equipment.
SRP Engineering offers hot dip galvanized poles of octagonal cross section customized as per client requirement which can be used for illumination, power transmission & distribution and various other purposes. These poles are galvanized internally and externally after fabrication in accordance with IS-2629/ BSEN ISO 1461 or equivalent.
Tubular poles are used for illumination of streets, highways, play grounds etc. We have a technical team for installation and commissioning of tubular poles dimensions and technical specifications can be change as per customer requirement lets have some look on standard technical details of tubular poles on next three pages.
SRP Engineering is a trusted supplier of decorative poles and brackets for street and garden lighting.
We offer a wide selection of cast iron poles, classic lamp posts, GI & MS street-light poles, and decorative brackets suitable for gardens, lawns, pathways, and urban streets.
All products come with premium rust-resistant finishes such as PU painting, powder coating, or hot-dip galvanizing, ensuring durability and low maintenance.
SRP Engineering highmast Offering range starts from 9m to 30m. We also provide civil and Structural design and we have technical team for project planning and its execution Highmast is generally used for illumination of large areas, on highways, play grounds etc.
Our Copper Pipes and Tubes for Air Conditioning and Refrigeration (ACR) applications are manufactured with high precision to meet international. These copper tubes ensure excellent heat transfer, corrosion resistance, and durability — making them ideal for use in HVAC, refrigeration, and cooling systems.
SUBMERSIBLE CABLE
Introduction
Single & Multicore Flexible Copper Cable are used in low voltage signals, electrical motors, electrical appliances, control panels, DC power transformers, electrical boards, battery cables etc.
These cables are highly flexible in construction & designed with high Di-electric strength.
Single & Multicore Flexible Copper Cable are having high degree of thermal stability, Oxygen & temperature index. These cables retard its spread in the unlikely event of fire felicitating rescue operation.
Applications
These wires/cables are used for wiring in control panels, machines and various electrical installations in dry and damp interiors especially under typical industrial environmental conditions.
Features
These wires are manufactured from bright-annealed 99.97% pure bare copper conductors and hence, offer low conductor resistance. The sheathing is provided with a specially formulated PVC compound to facilitate not only ease in stripping but also to withstand all kinds of mechanical abrasion while in use. PVC compounds used for insulation and sheathing have a high oxygen and temperature index & these properties help in restricting the spread of fire.
Cable Structure
Single Core Flexibles
| Typical Applications | Wiring of panels for use in high ambient temperature | Wiring in High density critical installations in public places and fire prone areas | Wiring in high density critical installations in public places and vicinity of electronic systems | Applicable Standards | IS-694, BS 6004, IEC 60227, DIN VDE-0281-3 | IEC 60332-1, BS 4066-1, EIC-60754-1, ASTMD-2843, ASTMD-2863 | IEC 60332-1&3, BS 4066-1&3, IEC 60754-1&2, ASTMD-2863, BS 7211, DIN VDE-0282-9 |
|---|
Multicore Flexibles
| Type of Insulation | Type of Sheathing | Applicable Standards | Typical Applications | Standard PVC | Standard PVC, HRPVC | IS 694, BS 6500, IEC 60227, DIN VDE-0281 | Power Cords for appliance, temporary power supplies, 3 core flat cables are suitable for submersible pump applications. |
|---|
| Heat Resistant PVC up to 105°C | Standard PVC, HRPVC | IS 694, BS 6500, IEC 60227, DIN VDE-0281 | Hi-power appliances, ovens, temporary power supply in higher temperature areas. | Standard PVC of FRLS | FRLS (Flame Retardant Low Smoke) | IS 694, BS 6500, IEC 60227, DIN VDE-0281, IEC 60754-1, IEC 60332-1, BS-4066-1, ASTMD 2843, ASTMD-2863 | Power cords for application used in fire prone areas, flame proof equipments, machine tools used in critical locations and heat zones. |
|---|
Why OUR Single Core & Multicore Flexible Cable
- Formulated with special PVC compound to work in challenging working condition & atmosphere.
- High on abrasion (Mechanical) withstand capacity.
- Excellent Fire & Heat retardant characteristics.
- Better reliability, energy efficiency & highest level of safety with high Oxygen Index.
- Highly flexible in nature felicitate easy handling at site
